EXC 1501 SPLINE® ONE

Tough enduro carbon rim paired with a durable 240 hub - a package for going fast.

  • MSRP per set US$ from $ 1899
  • Weight per set from 1609 g
Product details

Product details

The EXC 1501 SPLINE ONE combine everything a modern enduro rider wants in one wheelset. The 30 mm wide carbon rims give you the precision to stay on track even on the trickiest lines while a 240 hub with the latest RATCHET EXP freehub system puts your power down to the ground. Both components are held together by performance weight optimized competition race straightpull spokes.

  • Hub type 240 with Ratchet EXP 36
  • Rim Carbon, Tubeless str side/hookless TSS
  • Inner width 30 mm
  • Spokes DT competition® race straightp
Technologies

1501
carbonized

Carbon makes it possible to build lighter wheels, which improve riding behavior of the specific wheels for various fields of application.

technology

We believe in the art of engineering and strive for sophistication in the product development process. Our guiding idea is to constantly push barriers with our inhouse developed technologies.

Tubeless
Technology

Read

Prolock
Technology

Read

engagement angle
technology

Learn more

Ratchet exp
Technology

Learn more

Bearing
technology

Learn more
Models

Model finder

Just a few clicks to find your model. Please use the filter below.

03

Axle system

04

Built-in dimension

05

Freehub body

There are 8 models of this product.
Show all
Hide all
Zoom image
REAR WHEEL

EXC 1501 SPLINE ONE 29 - 30 mm IS 12/148 mm Sram

WEXC150TFDRCA11501
General
  • Net weight 899 g
  • recommended system weight max. 130 kg
  • ASTM classification 4
Rim
  • Material Carbon
  • Rim joint -
  • Tire interface Tubeless str side/Hookless TSS
  • Valve hole Presta
  • Rim Diameter 29" / 700C
  • Decal type Waterslide
  • Inner Width 30 mm
  • Outer width 36 mm
  • Cross-section
Hub Spokes & Nipples
  • Spokes left DT competition® race straightp
  • Spokes right DT competition® race straightp
  • Spoke pattern Three-cross (1:1)
  • Nipples DT Prolock Squorx ProHead alu
Inclusive
  • Inclusive Tubeless tape 32 mm
    TL valve alu black 18-25 mm
    Shim Micro Spline freehub kit
Zoom image
REAR WHEEL

EXC 1501 SPLINE ONE 29 - 30 mm CL 12/148 mm Sram

WEXC150TEDRCA11498

  • Net weight 891 g
  • recommended system weight max. 130 kg
  • ASTM classification 4

  • Material Carbon
  • Rim joint -
  • Tire interface Tubeless str side/Hookless TSS
  • Valve hole Presta
  • Rim Diameter 29" / 700C
  • Decal type Waterslide
  • Inner Width 30 mm
  • Outer width 36 mm
  • Cross-section

  • Spokes left DT competition® race straightp
  • Spokes right DT competition® race straightp
  • Spoke pattern Three-cross (1:1)
  • Nipples DT Prolock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    TL valve alu black 18-25 mm
    Shim Micro Spline freehub kit
Zoom image
REAR WHEEL

EXC 1501 SPLINE ONE 27.5 - 30 mm IS 12/148 mm Sram

WEXC150THDRCA11495

  • Net weight 857 g
  • recommended system weight max. 130 kg
  • ASTM classification 4

  • Material Carbon
  • Rim joint -
  • Tire interface Tubeless str side/Hookless TSS
  • Valve hole Presta
  • Rim Diameter 27.5" / 650B
  • Decal type Waterslide
  • Inner Width 30 mm
  • Outer width 36 mm
  • Cross-section

  • Spokes left DT competition® race straightp
  • Spokes right DT competition® race straightp
  • Spoke pattern Three-cross (1:1)
  • Nipples DT Prolock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    TL valve alu black 18-25 mm
    Shim Micro Spline freehub kit
Zoom image
REAR WHEEL

EXC 1501 SPLINE ONE 27.5 - 30 mm CL 12/148 mm Sram

WEXC150TGDRCA11492

  • Net weight 849 g
  • recommended system weight max. 130 kg
  • ASTM classification 4

  • Material Carbon
  • Rim joint -
  • Tire interface Tubeless str side/Hookless TSS
  • Valve hole Presta
  • Rim Diameter 27.5" / 650B
  • Decal type Waterslide
  • Inner Width 30 mm
  • Outer width 36 mm
  • Cross-section

  • Spokes left DT competition® race straightp
  • Spokes right DT competition® race straightp
  • Spoke pattern Three-cross (1:1)
  • Nipples DT Prolock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    TL valve alu black 18-25 mm
    Shim Micro Spline freehub kit
Zoom image
FRONT WHEEL

EXC 1501 SPLINE ONE 29 - 30 mm IS 15/110 mm

WEXC150BFIXCA11499

  • Net weight 802 g
  • recommended system weight max. 130 kg
  • ASTM classification 4

  • Material Carbon
  • Rim joint -
  • Tire interface Tubeless str side/Hookless TSS
  • Valve hole Presta
  • Rim Diameter 29" / 700C
  • Decal type Waterslide
  • Inner Width 30 mm
  • Outer width 36 mm
  • Cross-section

  • Spokes left DT competition® race straightp
  • Spokes right DT competition® race straightp
  • Spoke pattern Three-cross (1:1)
  • Nipples DT Prolock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    TL valve alu black 18-25 mm
Zoom image
FRONT WHEEL

EXC 1501 SPLINE ONE 29 - 30 mm CL 15/110 mm

WEXC150BEIXCA11496

  • Net weight 802 g
  • recommended system weight max. 130 kg
  • ASTM classification 4

  • Material Carbon
  • Rim joint -
  • Tire interface Tubeless str side/Hookless TSS
  • Valve hole Presta
  • Rim Diameter 29" / 700C
  • Decal type Waterslide
  • Inner Width 30 mm
  • Outer width 36 mm
  • Cross-section

  • Spokes left DT competition® race straightp
  • Spokes right DT competition® race straightp
  • Spoke pattern Three-cross (1:1)
  • Nipples DT Prolock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    TL valve alu black 18-25 mm
Zoom image
FRONT WHEEL

EXC 1501 SPLINE ONE 27.5 - 30 mm IS 15/110 mm

WEXC150BHIXCA11493

  • Net weight 760 g
  • recommended system weight max. 130 kg
  • ASTM classification 4

  • Material Carbon
  • Rim joint -
  • Tire interface Tubeless str side/Hookless TSS
  • Valve hole Presta
  • Rim Diameter 27.5" / 650B
  • Decal type Waterslide
  • Inner Width 30 mm
  • Outer width 36 mm
  • Cross-section

  • Spokes left DT competition® race straightp
  • Spokes right DT competition® race straightp
  • Spoke pattern Three-cross (1:1)
  • Nipples DT Prolock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    TL valve alu black 18-25 mm
Zoom image
FRONT WHEEL

EXC 1501 SPLINE ONE 27.5 - 30 mm CL 15/110 mm

WEXC150BGIXCA11490

  • Net weight 760 g
  • recommended system weight max. 130 kg
  • ASTM classification 4

  • Material Carbon
  • Rim joint -
  • Tire interface Tubeless str side/Hookless TSS
  • Valve hole Presta
  • Rim Diameter 27.5" / 650B
  • Decal type Waterslide
  • Inner Width 30 mm
  • Outer width 36 mm
  • Cross-section

  • Spokes left DT competition® race straightp
  • Spokes right DT competition® race straightp
  • Spoke pattern Three-cross (1:1)
  • Nipples DT Prolock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    TL valve alu black 18-25 mm

WHEEL GUIDES

Rim height, rim inner width, diameter of a wheel and the brake system influence the handling and riding performance of a bicycle significantly. Each rim has its own specific characteristics. Find out what suits your needs the best!
