ER 1600 SPLINE®

Ride further faster with this ideal upgrade to your bike.

  • MSRP per set US$ from $ 758
  • Weight per set from 1664 g
  • Brake interface Disc Brake
  • from € 599
  • from CHF 631
Product details

Product details

It is easy to lose track of time on these Endurance wheels. Thanks to the 22mm rim and the mix of comfort and grip provided by the ideal support of wide tires, you can easily change your plans and extend the ride. You will enjoy the quick engagement of the 350 hub with 36 SL Ratchet which, combined with the strong spokes, will give you a smooth ride even on technical roads. Available in two specific rim heights, the 30mm has been aero optimized to help you go further (or faster), whichever you prefer...
ER 1600 SPLINE 23: makes the hills you may encounter along the way barely noticeable
ER 1600 SPLINE 30: its aero-optimized design will keep you going in windy conditions

  • Hub type 350 with Ratchet System 36 SL
  • Rim Aluminum, Hooked / Crotchet tubeless TC
  • Rim height 23 mm, 30 mm
  • Spokes DT aero comp® II straightpull, DT aero comp® wide straightp
RIM WIDTH The new rim has an increased width of 22mm, providing ideal support for wide tires, resulting in a great mix of comfort and stability.
RIM HEIGHT The 30 mm height of the aero optimized design of the new E 550 rim will help you ride further.
SPOKES The DT aero comp® II straightpull has an updated shape from the previous version, providing an aerodynamic advantage.
HUB The 350 road hub saves some weight by using a lightweight axle along with a milled hub body and includes the prized Ratchet System.
FREEHUB BODY The fast engagement of the beloved Ratchet System 36 SL results in responsive acceleration, ideal when riding on winding roads.

AERO FOR ALL

Our first aero-optimized aluminum wheels

Technologies

technology

We believe in the art of engineering and strive for sophistication in the product development process. Our guiding idea is to constantly push barriers with our inhouse developed technologies.

Aero+
technology

Learn more

ratchet TECHNOLOGies
 OVERVIEW

Learn more

Tubeless
Technology

Read

Bearing
technology

Learn more

Spoke
Technology

Read

experienced
handbuilding

Models

Model finder

Just a few clicks to find your model. Please use the filter below.

01

Brake Interface

Disc Center Lock
02

Rim Height

03

Rim Diameter

04

Axle system

05

Built-in dimension

06

Cassette interface

There are 9 models of this product.
Show all
Hide all
Zoom image
Rear Wheel

ER 1600 SPLINE db 30 12/142 mm Shimano

WER1600NIDISA21172
General Rim Hub Spokes & Nipples
  • Spokes left DT aero comp® II Straightpull
  • Spokes right DT aero comp® II Straightpull
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu
Inclusive
  • Inclusive Tubeless tape 25 mm
    TL valve alu black 26-35 mm
Zoom image
Rear Wheel

ER 1600 SPLINE db 30 12/142 mm Sram XDR

WER1600NID1SA21173

  • Spokes left DT aero comp® II Straightpull
  • Spokes right DT aero comp® II Straightpull
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    TL valve alu black 26-35 mm
Zoom image
Rear Wheel

ER 1600 SPLINE 650b db 30 12/142 mm Shimano

WER1600NJDISA21844

  • Spokes left DT aero comp® II Straightpull
  • Spokes right DT aero comp® II Straightpull
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    TL valve alu black 26-35 mm
Zoom image
Rear Wheel

ER 1600 SPLINE 650b db 30 12/142 mm Sram XDR

WER1600NJD1SA21845

  • Spokes left DT aero comp® II Straightpull
  • Spokes right DT aero comp® II Straightpull
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    TL valve alu black 26-35 mm
Zoom image
Rear Wheel

ER 1600 SPLINE db 23 12/142 mm Shimano

WER1600NIDISA21178

  • Spokes left DT aero comp® wide straightp
  • Spokes right DT aero comp® wide straightp
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    TL valve alu black 18-25 mm
Zoom image
Rear Wheel

ER 1600 SPLINE db 23 12/142 mm Sram XDR

WER1600NID1SA21179

  • Spokes left DT aero comp® wide straightp
  • Spokes right DT aero comp® wide straightp
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    TL valve alu black 18-25 mm
Zoom image
Front Wheel

ER 1600 SPLINE db 30 12/100 mm

WER1600AIDXSA21171

  • Spokes left DT aero comp® II Straightpull
  • Spokes right DT aero comp® II Straightpull
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    TL valve alu black 26-35 mm
Zoom image
Front Wheel

ER 1600 SPLINE 650b db 30 12/100 mm

WER1600AJDXSA21843

  • Spokes left DT aero comp® II Straightpull
  • Spokes right DT aero comp® II Straightpull
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    TL valve alu black 26-35 mm
Zoom image
Front Wheel

ER 1600 SPLINE db 23 12/100 mm

WER1600AIDXSA21177

  • Spokes left DT aero comp® wide straightp
  • Spokes right DT aero comp® wide straightp
  • Spoke pattern Two-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    TL valve alu black 18-25 mm
Support

  • Looking for conversion options, spare parts, manuals or how-to videos? Visit our product support.

  • Find help and answers for frequently asked questions here.

According to your selection ER 1600 SPLINE® we found 9 models. Please use the model finder above to narrow down the models.
Select the model for which you need product support.

Find help and answers for frequently asked questions here.

  • The current DT Swiss wheels are tubeless-ready and come with mounted tubeless rim tape and corresponding valves. For conversion, you will need a tubeless-capable tire (optimal: UST) and tire sealant. You can find both at an official dealer. Our How To video will take you through step-by-step assembly.



    If you have previously ridden your bike with a tube or if the tape no longer sticks properly to the rim, we recommend that you replace the rim tape as a precaution.

    How to attach the tubeless rim tape:

    1. Measure the inside width of the rim.

    2. The tubeless rim tape should be approx. 2 mm wider than the rim and can be bought from a specialist store.

    3. Apply the tubeless rim tape. Depending on the rim/tire combination, it may be helpful to apply two or three layers of tubeless rim tape to optimally seal the rim bed.

    Play global.youtube.alt
    47

  • Under Product Support, you will find exact details of all conversion options for your product (wheel, hub). First go to Product Support and select your product using the DT Swiss ID or filter. Under "Conversion" you will find the exact details for all conversion options. You will also find helpful How To videos and manuals.

    65

  • DT Swiss sells its products exclusively via official dealers, some of which also have online shops. Please contact your dealer. Or contact the distributor for your country – please use the contact form and select your country first, followed by "Product availability" as the subject.

    31

  • Unfortunately we don't offer discounts; we don't sell directly to private customers. Please contact a dealer. You can find recommended retail prices on our website.

    48

  • Compare the products on our website, where you can find our entire range and all technical specifications. Use the Wheel Finder to find the right wheel in just a few clicks.

    Alternatively, contact a dealer – they know all about DT Swiss products and technologies and can advise you.
