X 1900 SPLINE®
Enter the world of XC with a reliable wheelset to focus on the essential moments.
- MSRP per set US$ from $ 609
- Weight per set from 1844 g
Product details
Enter the Cross Country world with the X 1900 SPLINE. The 25 mm wide aluminum rim offers modern tires the support needed to ride low air pressure in order to minimize rolling resistance. The new Ratchet LN freehub system and meticulous wheel building by hand ensure the highest reliability. This allows riders to just focus on the moment - whether it is beating the sweat out of their opponents or beating their own KOM or QOM.
- Hub type 370 with Ratchet LN 18
- Rim Aluminum, Hooked / Crotchet tubeless TC
- Inner width 25 mm
- Spokes DT champion® straightpull





Model finder
Just a few clicks to find your model. Please use the filter below.

X 1900 SPLINE 29 - 25 mm CL 12/142 mm Shimano
W0X1900NEDLSA18971- Net weight 1002 g
- recommended System weight max. 110 kg
- ASTM classification 3
- Material Aluminum
- Rim joint Sleeve joint
- Tire interface Hooked / Crotchet tubeless TC
- Valve hole Presta
- Rim Diameter 29" / 700C
- Decal type Waterslide
- Inner Width 25 mm
- Outer width 29 mm
-
Cross-section
- Hub type 370
- Axle system 12 mm Thru Axle
- Built-in dimension 142 mm
- Brake Interface Disc Center Lock
- Cassette interface Shimano MTB
- Freehub body Shimano Forged (ASF)
- Freehub system Ratchet LN 18
- Spokes left DT champion® Straightpull
- Spokes right DT champion® Straightpull
- Spoke pattern Three-cross (1:1)
- Nipples DT ProLock Squorx ProHead alu
-
Inclusive
Tubeless tape 27 mm
Tubeless valve MTB 32 mm
IS 6-bolt adapter MTB

X 1900 SPLINE 29 - 25 mm CL 12/142 mm Sram
W0X1900NEDRSA20529- Net weight 979 g
- recommended System weight max. 110 kg
- ASTM classification 3
- Material Aluminum
- Rim joint Sleeve joint
- Tire interface Hooked / Crotchet tubeless TC
- Valve hole Presta
- Rim Diameter 29" / 700C
- Decal type Waterslide
- Inner Width 25 mm
- Outer width 29 mm
-
Cross-section
- Hub type 370
- Axle system 12 mm Thru Axle
- Built-in dimension 142 mm
- Brake Interface Disc Center Lock
- Cassette interface Sram XD
- Freehub body SRAM XD MTB (ASRAM)
- Freehub system Ratchet LN 18
- Spokes left DT champion® Straightpull
- Spokes right DT champion® Straightpull
- Spoke pattern Three-cross (1:1)
- Nipples DT ProLock Squorx ProHead alu
-
Inclusive
Tubeless tape 27 mm
Tubeless valve MTB 32 mm
IS 6-bolt adapter MTB

X 1900 SPLINE 29 - 25 mm CL 12/148 mm Shimano
W0X1900TED2SA18789- Net weight 992 g
- recommended System weight max. 110 kg
- ASTM classification 3
- Material Aluminum
- Rim joint Sleeve joint
- Tire interface Hooked / Crotchet tubeless TC
- Valve hole Presta
- Rim Diameter 29" / 700C
- Decal type Waterslide
- Inner Width 25 mm
- Outer width 29 mm
-
Cross-section
- Hub type 370
- Axle system 12 mm Thru Axle
- Built-in dimension 148 mm Boost
- Brake Interface Disc Center Lock
- Cassette interface Shimano Micro Spline
- Freehub body Shim. 12SP Light (ASL12)
- Freehub system Ratchet LN 18
- Spokes left DT champion® Straightpull
- Spokes right DT champion® Straightpull
- Spoke pattern Three-cross (1:1)
- Nipples DT ProLock Squorx ProHead alu
-
Inclusive
Tubeless tape 27 mm
Tubeless valve MTB 32 mm
IS 6-bolt adapter MTB

X 1900 SPLINE 29 - 25 mm CL 12/148 mm Shimano
W0X1900TEDLSA18790- Net weight 1006 g
- recommended System weight max. 110 kg
- ASTM classification 3
- Material Aluminum
- Rim joint Sleeve joint
- Tire interface Hooked / Crotchet tubeless TC
- Valve hole Presta
- Rim Diameter 29" / 700C
- Decal type Waterslide
- Inner Width 25 mm
- Outer width 29 mm
-
Cross-section
- Hub type 370
- Axle system 12 mm Thru Axle
- Built-in dimension 148 mm Boost
- Brake Interface Disc Center Lock
- Cassette interface Shimano MTB
- Freehub body Shimano Forged (ASF)
- Freehub system Ratchet LN 18
- Spokes left DT champion® Straightpull
- Spokes right DT champion® Straightpull
- Spoke pattern Three-cross (1:1)
- Nipples DT ProLock Squorx ProHead alu
-
Inclusive
Tubeless tape 27 mm
Tubeless valve MTB 32 mm
IS 6-bolt adapter MTB

X 1900 SPLINE 29 - 25 mm CL 12/148 mm SRAM
W0X1900TEDRSA18806- Net weight 983 g
- recommended System weight max. 110 kg
- ASTM classification 3
- Material Aluminum
- Rim joint Sleeve joint
- Tire interface Hooked / Crotchet tubeless TC
- Valve hole Presta
- Rim Diameter 29" / 700C
- Decal type Waterslide
- Inner Width 25 mm
- Outer width 29 mm
-
Cross-section
- Hub type 370
- Axle system 12 mm Thru Axle
- Built-in dimension 148 mm Boost
- Brake Interface Disc Center Lock
- Cassette interface Sram XD
- Freehub body SRAM XD MTB (ASRAM)
- Freehub system Ratchet LN 18
- Spokes left DT champion® Straightpull
- Spokes right DT champion® Straightpull
- Spoke pattern Three-cross (1:1)
- Nipples DT ProLock Squorx ProHead alu
-
Inclusive
Tubeless tape 27 mm
Tubeless valve MTB 32 mm
IS 6-bolt adapter MTB

X 1900 SPLINE 29 - 25 mm CL 15/100 mm
W0X1900AEIXSA18970- Net weight 865 g
- recommended System weight max. 110 kg
- ASTM classification 3
- Material Aluminum
- Rim joint Sleeve joint
- Tire interface Hooked / Crotchet tubeless TC
- Valve hole Presta
- Rim Diameter 29" / 700C
- Decal type Waterslide
- Inner Width 25 mm
- Outer width 29 mm
-
Cross-section
- Hub type 370
- Axle system 15 mm Thru Axle
- Built-in dimension 100 mm
- Brake Interface Disc Center Lock
- Cassette interface -
- Freehub body -
- Freehub system -
- Spokes left DT champion® Straightpull
- Spokes right DT champion® Straightpull
- Spoke pattern Three-cross (1:1)
- Nipples DT ProLock Squorx ProHead alu
-
Inclusive
Tubeless tape 27 mm
Tubeless valve MTB 32 mm
IS 6-bolt adapter MTB

X 1900 SPLINE 29 - 25 mm CL 15/110 mm
W0X1900BEIXSA18788- Net weight 872 g
- recommended System weight max. 110 kg
- ASTM classification 3
- Material Aluminum
- Rim joint Sleeve joint
- Tire interface Hooked / Crotchet tubeless TC
- Valve hole Presta
- Rim Diameter 29" / 700C
- Decal type Waterslide
- Inner Width 25 mm
- Outer width 29 mm
-
Cross-section
- Hub type 370
- Axle system 15 mm Thru Axle
- Built-in dimension 110 mm Boost
- Brake Interface Disc Center Lock
- Cassette interface -
- Freehub body -
- Freehub system -
- Spokes left DT champion® Straightpull
- Spokes right DT champion® Straightpull
- Spoke pattern Three-cross (1:1)
- Nipples DT ProLock Squorx ProHead alu
-
Inclusive
Tubeless tape 27 mm
Tubeless valve MTB 32 mm
IS 6-bolt adapter MTB

Product support
Manuals, how-to videos, spareparts & conversion.
According to your selection X 1900 SPLINE® we found 7 models. Please use the model finder above to narrow down the models.
Select the model for which you need product support.
