X 1900 SPLINE®

Our Cross Country workhorse - race feeling without breaking the bank.

  • MSRP per set US$ from $ 427
  • Weight per set from 1721 g
Product details

Product details

The X 1900 SPLINE has everything a modern wheel needs. The strong, lightweight rim guarantees optimum acceleration, while the high-precision freewheel minimizes resistance and maximizes lifespan. The components are held together with 28 extremely durable straightpull spokes. Maximum trail fun without breaking the bank. The high-quality finish and the classy look will turn heads. Unfortunately for your competitors, they’ll only get a short, jealous glance as you fly past them.

  • Hub type 370 with 3 Pawl
  • Rim Aluminum, Clincher
  • Inner width 22.5 mm, 25 mm
  • Spokes DT champion® straightpull
Technologies

technology

We believe in the art of engineering and strive for sophistication in the product development process. Our guiding idea is to constantly push barriers with our inhouse developed technologies.

Tubeless
Technology

Read

engagement angle
technology

Learn more

Prolock
Technology

Read
Models

Model finder

Just a few clicks to find your model. Please use the filter below.

01

Rim diameter

02

Inner width

03

Axle system

04

Built-in dimension

05

Freehub body

06

Brake interface

There are 26 models of this product.
Show all
Hide all
REAR WHEEL

X 1900 SPLINE 29 - 22.5 mm CL 12/142 mm Shimano

W0X1900NEDTSA06808
General
  • Net weight 978 g
  • recommended system weight max. 110 kg
  • ASTM classification 3
Rim
  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section
Hub
  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl
Spokes & Nipples
  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu
Inclusive
  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 29 - 22.5 mm CL 12/142 mm Sram

W0X1900NEDQSA06809

  • Net weight 960 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 29 - 22.5 mm CL 12/148 mm Shimano

W0X1900TEDTSA06810

  • Net weight 983 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 29 - 22.5 mm CL 12/148 mm Sram

W0X1900TEDQSA06811

  • Net weight 966 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 22.5 mm CL 12/142 mm Shimano

W0X1900NGDTSA06796

  • Net weight 939 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 22.5 mm CL 12/142 mm Sram

W0X1900NGDQSA06797

  • Net weight 921 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 22.5 mm CL 12/148 mm Shimano

W0X1900TGDTSA06798

  • Net weight 944 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 22.5 mm CL 12/148 mm Sram

W0X1900TGDQSA06799

  • Net weight 927 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 29 - 25 mm CL 12/142 mm Shimano

W0X1900NEDTSA06836

  • Net weight 1002 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 29 - 25 mm CL 12/142 mm Sram

W0X1900NEDQSA06837

  • Net weight 984 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 29 - 25 mm CL 12/148 mm Shimano

W0X1900TED3SA11083

  • Net weight 1027 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano 12SP Steel (SS12)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 29 - 25 mm CL 12/148 mm Shimano

W0X1900TEDTSA06838

  • Net weight 1007 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 29 - 25 mm CL 12/148 mm Sram

W0X1900TEDQSA06839

  • Net weight 990 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 25 mm CL 12/142 mm Shimano

W0X1900NGDTSA06824

  • Net weight 958 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 25 mm CL 12/142 mm Sram

W0X1900NGDQSA06825

  • Net weight 940 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 25 mm CL 12/148 mm Shimano

W0X1900TGD3SA11082

  • Net weight 983 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano 12SP Steel (SS12)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 25 mm CL 12/148 mm Shimano

W0X1900TGDTSA06826

  • Net weight 963 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

X 1900 SPLINE 27.5 - 25 mm CL 12/148 mm Sram

W0X1900TGDQSA06827

  • Net weight 946 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

X 1900 SPLINE 29 - 22.5 mm CL 15/100 mm

W0X1900AEIXSA06806

  • Net weight 838 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

X 1900 SPLINE 29 - 22.5 mm CL 15/110 mm

W0X1900BEIXSA06807

  • Net weight 845 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

X 1900 SPLINE 27.5 - 22.5 mm CL 15/100 mm

W0X1900AGIXSA06794

  • Net weight 800 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

X 1900 SPLINE 27.5 - 22.5 mm CL 15/110 mm

W0X1900BGIXSA06795

  • Net weight 807 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 22.5 mm
  • Outer width 27 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 25 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

X 1900 SPLINE 29 - 25 mm CL 15/100 mm

W0X1900AEIXSA06834

  • Net weight 863 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

X 1900 SPLINE 29 - 25 mm CL 15/110 mm

W0X1900BEIXSA06835

  • Net weight 870 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

X 1900 SPLINE 27.5 - 25 mm CL 15/100 mm

W0X1900AGIXSA06822

  • Net weight 818 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

X 1900 SPLINE 27.5 - 25 mm CL 15/110 mm

W0X1900BGIXSA06823

  • Net weight 825 g
  • recommended system weight max. 110 kg
  • ASTM classification 3

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 29 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
Support

Product support

Find manuals, how-to videos and helpful online forms here.

According your selection X 1900 SPLINE® we found 26 models. Select the model for which you need product support.
