M 1900 SPLINE®

The do it all wheel - bringing high end tech into an affordable wheel.

  • MSRP per set US$ from $ 439
  • Weight per set from 1798 g
Product details

Product details

M 1900 SPLINE means business. It’s been developed for the new all-mountain bikes. We’ve packed all our expertise into the high-end machined hubs of the M 1900 SPLINE. Forces to and from the hubs are transmitted via our proven straight pull spokes. The strong, lightweight rims of either 25, 30 or 35 mm innerwidth offer the best tiresupport for your prefered tirewidth and meet all the demands of a tubeless setup and modern MTB tires - they’ll have you flying up and down the mountains.

  • Hub type 370 with 3 Pawl
  • Rim Aluminum, Clincher
  • Inner width 25 mm, 30 mm, 35 mm
  • Spokes DT champion® straightpull
Technologies

technology

We believe in the art of engineering and strive for sophistication in the product development process. Our guiding idea is to constantly push barriers with our inhouse developed technologies.

Tubeless
Technology

Read

engagement angle
technology

Learn more

Prolock
Technology

Read
Models

Model finder

Just a few clicks to find your model. Please use the filter below.

01

Rim diameter

02

Inner width

03

Axle system

04

Built-in dimension

05

Freehub body

06

Brake interface

There are 34 models of this product.
Show all
Hide all
REAR WHEEL

M 1900 SPLINE 29 - 25 mm CL 12/142 mm Shimano

W0M1900NEDTSA06947
General
  • Net weight 1022 g
  • max. system weight 120 kg
  • ASTM classification 4
Rim
  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section
Hub
  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl
Spokes & Nipples
  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu
Inclusive
  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 25 mm CL 12/142 mm Sram

W0M1900NEDQSA06948

  • Net weight 1004 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 25 mm CL 12/148 mm Shimano

W0M1900TED3SA11085

  • Net weight 1047 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano 12SP Steel (SS12)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 25 mm CL 12/148 mm Shimano

W0M1900TEDTSA06949

  • Net weight 1027 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 25 mm CL 12/148 mm Sram

W0M1900TEDQSA06950

  • Net weight 1010 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 25 mm CL 12/142 mm Shimano

W0M1900NGDTSA06935

  • Net weight 978 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 25 mm CL 12/142 mm Sram

W0M1900NGDQSA06936

  • Net weight 960 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 25 mm CL 12/148 mm Shimano

W0M1900TGD3SA11084

  • Net weight 1003 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano 12SP Steel (SS12)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 25 mm CL 12/148 mm Shimano

W0M1900TGDTSA06937

  • Net weight 983 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 25 mm CL 12/148 mm Sram

W0M1900TGDQSA06938

  • Net weight 966 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 30 mm CL 12/142 mm Shimano

W0M1900NEDTSA06975

  • Net weight 1081 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 30 mm CL 12/142 mm Sram

W0M1900NEDQSA06976

  • Net weight 1063 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 30 mm CL 12/148 mm Shimano

W0M1900TED3SA11087

  • Net weight 1107 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano 12SP Steel (SS12)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 30 mm CL 12/148 mm Shimano

W0M1900TEDTSA06977

  • Net weight 1087 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 29 - 30 mm CL 12/148 mm Sram

W0M1900TEDQSA06978

  • Net weight 1070 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 30 mm CL 12/142 mm Shimano

W0M1900NGDTSA06963

  • Net weight 1033 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 30 mm CL 12/142 mm Sram

W0M1900NGDQSA06964

  • Net weight 1015 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 30 mm CL 12/148 mm Shimano

W0M1900TGD3SA11086

  • Net weight 1058 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano 12SP Steel (SS12)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 30 mm CL 12/148 mm Shimano

W0M1900TGDTSA06965

  • Net weight 1038 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 30 mm CL 12/148 mm Sram

W0M1900TGDQSA06966

  • Net weight 1021 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 35 mm CL 12/142 mm Shimano

W0M1900NGDTSA06987

  • Net weight 1068 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 35 mm
  • Outer width 40 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 37 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 35 mm CL 12/142 mm Sram

W0M1900NGDQSA06988

  • Net weight 1050 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 35 mm
  • Outer width 40 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 142 mm
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 37 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 35 mm CL 12/148 mm Shimano

W0M1900TGDTSA06989

  • Net weight 1073 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 35 mm
  • Outer width 40 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body Shimano Alu/Steel (ASS)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 37 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
REAR WHEEL

M 1900 SPLINE 27.5 - 35 mm CL 12/148 mm Sram

W0M1900TGDQSA06990

  • Net weight 1056 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 35 mm
  • Outer width 40 mm
  • Cross-section

  • Hub type 370
  • Axle system 12 mm Thru Axle
  • Built-in dimension 148 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body SRAM XD MTB Alu/Steel (ASSRAM)
  • Freehub system 3 Pawl

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 37 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 29 - 25 mm CL 15/100 mm

W0M1900AEIXSA06945

  • Net weight 883 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 29 - 25 mm CL 15/110 mm

W0M1900BEIXSA06946

  • Net weight 890 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 27.5 - 25 mm CL 15/100 mm

W0M1900AGIXSA06933

  • Net weight 838 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 27.5 - 25 mm CL 15/110 mm

W0M1900BGIXSA06934

  • Net weight 845 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 25 mm
  • Outer width 30 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 27 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 29 - 30 mm CL 15/100 mm

W0M1900AEIXSA06973

  • Net weight 943 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 29 - 30 mm CL 15/110 mm

W0M1900BEIXSA06974

  • Net weight 949 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 29" / 700C
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 27.5 - 30 mm CL 15/100 mm

W0M1900AGIXSA06961

  • Net weight 893 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 27.5 - 30 mm CL 15/110 mm

W0M1900BGIXSA06962

  • Net weight 900 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 30 mm
  • Outer width 35 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 32 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 27.5 - 35 mm CL 15/100 mm

W0M1900AGIXSA06985

  • Net weight 928 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 35 mm
  • Outer width 40 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 100 mm
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 37 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
FRONT WHEEL

M 1900 SPLINE 27.5 - 35 mm CL 15/110 mm

W0M1900BGIXSA06986

  • Net weight 935 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material Aluminum
  • Rim type Clincher
  • Rim diameter 27.5" / 650B
  • Decal type Hub vinyl / Rim waterslide
  • Inner width 35 mm
  • Outer width 40 mm
  • Cross-section

  • Hub type 370
  • Axle system 15 mm Thru Axle
  • Built-in dimension 110 mm Boost
  • Brake interface Disc Center Lock
  • Freehub body -
  • Freehub system -

  • Spokes DT champion® Straightpull
  • Spoke pattern 3-cross (1:1)
  • Nipples DT ProLock Squorx ProHead alu

  • Inclusive Tubeless tape 37 mm
    Tubeless valve MTB 32 mm
    IS 6-bolt adapter MTB
Support

Product support

Manuals, spareparts & conversion.

According to your selection M 1900 SPLINE® we found 34 models. Select the model for which you need product support.

Experience

by Rachael Wight

“If you value the quality of the wheel build, want a hard wearing wheelset with great ride quality and don’t mind the slower engagement of the hub then these wheels could be on your shopping list.”
