DT AERO COMP®

Are you looking for a balanced ratio of stiffness, aerodynamics and durability - then this is your spoke!

  • Length [mm] (L) 194 - 310
Product details

Product details

The middle section of this spoke is first butted through cold forging. This makes it more lightweight and stronger. In a further complex process, it is bladed to optimize the aerodynamic characteristics while increasing the material strength. DT Aero Comp guarantees a balanced ratio of stiffness, aerodynamics and durability. This spoke fits hubs with standard spoke holes. Weight: 380 g for 64 spokes at a length of 264 mm.

  • Product type J-bend, Straightpull
  • Blading Bladed
  • Reduction Double butted
Technologies

Technology

We believe in the art of engineering and strive for sophistication in the product development process. Our guiding idea is to constantly push barriers with our inhouse developed technologies.

Spoke
Technology

Read
Models

Model finder

Just a few clicks to find your model. Please use the filter below.

01

Product type

02

Color

03

Diameter 1 [mm] (D1)

There are 4 models of this product.
Show all
Hide all
Zoom image

DT aero comp silver 2.0 / 1.25 / 2.3 x ___ mm

SAC020___N0100
General
  • Product type J-Bend
  • Blading Bladed
  • Reduction Double butted
  • Recommended for e-bikes -
  • Color Silver
Dimensions
  • Length [mm] (L) 194 - 310
  • Diameter 1 [mm] (D1) 2
  • Diameter 2 [mm] (D2) 1.8
  • Diameter 3 [mm] (D3) 2
  • Width 1 [mm] (B1) 1.2
  • Width 2 [mm] (B2) 2.3
  • Thread 2.0 / FG 2.3
  • Height of head [mm] (H) 6.2
  • Angle (A) 90 - 95°
  • Gauges -
Zoom image

DT aero comp J-bend black 2.0 / 1.8 / 2.0 1.2 / 2.5

SAC020___S0100

  • Product type J-Bend
  • Blading Bladed
  • Reduction Double butted
  • Recommended for e-bikes -
  • Color Black

  • Length [mm] (L) 194 - 310
  • Diameter 1 [mm] (D1) 2
  • Diameter 2 [mm] (D2) 1.8
  • Diameter 3 [mm] (D3) 2
  • Width 1 [mm] (B1) 1.2
  • Width 2 [mm] (B2) 2.3
  • Thread 2.0 / FG 2.3
  • Height of head [mm] (H) 6.2
  • Angle (A) 90 - 95°
  • Gauges -
Zoom image

DT aero comp straight pull silver 2.0 / 1.25 / 2.3 x ___ mm

SACS20___N01000253

  • Product type Straightpull
  • Blading Bladed
  • Reduction Double butted
  • Recommended for e-bikes -
  • Color Silver

  • Length [mm] (L) 194 - 310
  • Diameter 1 [mm] (D1) 2
  • Diameter 2 [mm] (D2) 1.8
  • Diameter 3 [mm] (D3) 2
  • Width 1 [mm] (B1) 1.2
  • Width 2 [mm] (B2) 2.3
  • Thread 2.0 / FG 2.3
  • Height of head [mm] (H) -
  • Angle (A) -
  • Gauges -
Zoom image

DT aero comp straight pull black 2.0 / 1.8 / 2.0 1.2 / 2.7

SACS20___S01000253

  • Product type Straightpull
  • Blading Bladed
  • Reduction Double butted
  • Recommended for e-bikes -
  • Color Black

  • Length [mm] (L) 194 - 310
  • Diameter 1 [mm] (D1) 2
  • Diameter 2 [mm] (D2) 1.8
  • Diameter 3 [mm] (D3) 2
  • Width 1 [mm] (B1) 1.2
  • Width 2 [mm] (B2) 2.3
  • Thread 2.0 / FG 2.3
  • Height of head [mm] (H) -
  • Angle (A) -
  • Gauges -
