FR 560
30 mm welded rim, developed for the big gaps, nasty root mats and mean rockgardens.
- MSRP US$ from $ 133
- Net weight from 570 g
Product details
The FR 560 was made to withstand the nastiest of rock gardens, the roughest of roots and the sketchiest of landings. The prototype proved to be World Championship material and the final product is now available for you to shred as hard as you want. Available as a classic 26”, a 27.5” and as a 29” wagon wheel. The 30 mm inner rim width provides your tires with the support they need to roost through the berms at full speed.
- Material ALUMINIUM
Model finder
Just a few clicks to find your model. Please use the filter below.
Zoom image
FR 560 26 30 mm DB VI
RDFR56ADPS32SA8555- Net weight 570 g
- recommended system weight max. 140 kg
- ASTM classification 5
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Tubeless crotched/Clincher TC
- Brake Interface Disc
- Rim Diameter 26"
- Reference diameter ERD 538 mm
- Inner Width 30 mm
- Outer width 35 mm
- Rim Height 21 mm
-
Cross-section
- Number of holes 32
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
Zoom image
FR 560 26 30 mm DB VI
RDFR56ADPS32SB8555- Net weight 570 g
- recommended system weight max. 140 kg
- ASTM classification 5
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Tubeless crotched/Clincher TC
- Brake Interface Disc
- Rim Diameter 26"
- Reference diameter ERD 538 mm
- Inner Width 30 mm
- Outer width 35 mm
- Rim Height 21 mm
- Cross-section
- Number of holes 32
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
Zoom image
FR 560 27.5 30 mm DB VI
RDFR56BDPS32SA7488- Net weight 595 g
- recommended system weight max. 140 kg
- ASTM classification 5
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Tubeless crotched/Clincher TC
- Brake Interface Disc
- Rim Diameter 27.5" / 650B
- Reference diameter ERD 563 mm
- Inner Width 30 mm
- Outer width 35 mm
- Rim Height 21 mm
-
Cross-section
- Number of holes 32
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
Zoom image
FR 560 27.5 30 mm DB VI
RDFR56BDPS32SB7488- Net weight 595 g
- recommended system weight max. 140 kg
- ASTM classification 5
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Tubeless crotched/Clincher TC
- Brake Interface Disc
- Rim Diameter 27.5" / 650B
- Reference diameter ERD 563 mm
- Inner Width 30 mm
- Outer width 35 mm
- Rim Height 21 mm
- Cross-section
- Number of holes 32
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
Zoom image
FR 560 29 30 mm DB VI
RDFR56CDPS32SA4789- Net weight 635 g
- recommended system weight max. 140 kg
- ASTM classification 5
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Tubeless crotched/Clincher TC
- Brake Interface Disc
- Rim Diameter 29" / 700C
- Reference diameter ERD 601 mm
- Inner Width 30 mm
- Outer width 35 mm
- Rim Height 21 mm
-
Cross-section
- Number of holes 32
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
Zoom image
FR 560 29 30 mm DB VI
RDFR56CDPS32SB4789- Net weight 635 g
- recommended system weight max. 140 kg
- ASTM classification 5
- Material ALUMINIUM
- Rim joint Welded
- Tire interface Tubeless crotched/Clincher TC
- Brake Interface Disc
- Rim Diameter 29" / 700C
- Reference diameter ERD 601 mm
- Inner Width 30 mm
- Outer width 35 mm
- Rim Height 21 mm
- Cross-section
- Number of holes 32
- Spoke bore rim Silver eyelet
- Valve hole Presta
- Inclusive -
Product support
Manuals, spareparts & conversion.
According to your selection FR 560 we found 6 models. Select the model for which you need product support.
