XM 521

Light and wide - a 35 mm wide welded AM rim.

  • MSRP US$ from $ 164
  • Net weight from 545 g
Product details

Product details

Plus size tires are great and with the XM 521 they find their ideally matched counterpart. It offers all the support needed by the most aggressive of riders, yet it keeps the weight really low. This is important since big tires tempt you to goof around on the trails and any rider would rather spend their energy jumping off obstacles than wasting it dragging along extra weight. That's the XM 521: a rim ready to put smiles on riders' faces.

  • Material ALUMINIUM
Models

Model finder

Just a few clicks to find your model. Please use the filter below.

01

Rim diameter

27.5" / 650B
02

Number of holes

There are 2 models of this product.
Show all
Hide all

XM 521 27.5 35 mm DB VI

RDXM5265028S011557
General
  • Net weight 545 g
  • max. system weight 120 kg
  • ASTM classification 4
Material & Brake Interface
  • Material ALUMINIUM
  • Brake interface Disc
Dimensions
  • Rim diameter 27.5" / 650B
  • Reference diameter ERD 562 mm
  • Inner width 35 mm
  • Outer width 40 mm
  • Rim height 21 mm
  • Cross-section
Holes
  • Number of holes 28
  • Bore type Non-Eyelet (PHR washer)
Inclusive
  • Inclusive -

XM 521 27.5 35 mm DB VI

RDXM5265032S011558

  • Net weight 545 g
  • max. system weight 120 kg
  • ASTM classification 4

  • Material ALUMINIUM
  • Brake interface Disc

  • Rim diameter 27.5" / 650B
  • Reference diameter ERD 562 mm
  • Inner width 35 mm
  • Outer width 40 mm
  • Rim height 21 mm
  • Cross-section

  • Number of holes 32
  • Bore type Non-Eyelet (PHR washer)

  • Inclusive -
